Description
Product Overview
The BY255P-E3/54 is a general-purpose Plastic Rectifier with moulded epoxy body and matte tin-plated solderable leads. It is suitable for use in general-purpose rectification of power supplies, inverters, converters and freewheeling diodes application.
- Cathode is indicated by polarity band
- Low forward voltage drop
- High forward surge capability
- <lt/>0.1μA Typical IR low leakage current
Applications
Industrial, Power Management
Product details
| Repetitive Peak Reverse Voltage | 1.3kV |
| Diode Configuration | Single |
| Reverse Recovery Time | 3µs |
| Operating Temperature Max | 150°C |
| No. of Pins | 2Pins |
| Qualification | - |
| Average Forward Current | 3A |
| Forward Voltage Max | 1.1V |
| Forward Surge Current | 150A |
| Diode Case Style | DO-201AD |
| Product Range | BY255 |
| SVHC | Lead (04-Feb-2026) |
Other details
| Brand | VISHAY |
| Part Number | BY255P-E3/54 |
| Quantity | Each |
| Product Change Notice (87.21KB) EN | View or download |
| Technical Data Sheet (133.00B) EN | View or download |
