Description
Product Overview
The 1300061163 is a 1-ended A-size yellow Cordset with 5-position circular receptacle to free/strip connection. Comes with a PVC jacket, copper alloy contact, black epoxy coated zinc coupling nut and gold plating mating. The Mini-Change® receptacle features female straight to pigtail leads and single keyway. It also features rugged and sealed connectors in industrial applications. This connector provides the first quick-connect alternative to hard-wiring. To ensure a consistent and low-resistance connection the patented Quad Beam™ female contact is used. An anti-vibration feature prevents the coupler from loosening, even under extreme conditions.
- Cable is oil, water and UV resistant
- STOOW wire/cable
- Sealed to provide IP67 protection
- -20 to 105°C Operating temperature range
Applications
Industrial, Automation & Process Control, Commercial
Product details
| Connector Type A | Mini-Change Receptacle |
| No. of Positions | 5 Positions |
| Cable Length - Imperial | 6ft |
| SVHC | No SVHC (17-Dec-2014) |
| Connector Type B | Free End |
| Cable Length - Metric | 1.83m |
| Product Range | Mini-Change 130006 Series |
Other details
| Brand | MOLEX |
| Part Number | 130006-1163 |
| Quantity | Each |
| Product Change Notice (252.25KB) EN | View or download |
| Drawing (104.17KB) EN | View or download |
