Description
Product Overview
The AS1PM-M3/84A is a surface-mount standard Avalanche Rectifier with matte tin-plated solderable leads. It is suitable for use in general-purpose rectification of power supplies, inverters, converters and freewheeling diodes.
- Cathode is indicated by polarity colour band
- Glass-passivated pallet chip junction
- Very low profile
- Ideal for automated placement
- Controlled avalanche characteristics
- Low forward voltage drop
- Low leakage current
Applications
Industrial, Consumer Electronics, Communications & Networking, Automotive, Power Management, Commercial
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Repetitive Peak Reverse Voltage | 1kV |
| Diode Configuration | Single |
| Reverse Recovery Time | - |
| Operating Temperature Max | 175°C |
| No. of Pins | 2Pins |
| Qualification | - |
| Average Forward Current | 1.5A |
| Forward Voltage Max | 950mV |
| Forward Surge Current | 30A |
| Diode Case Style | DO-220AA |
| Product Range | AS1PM |
| SVHC | Lead (04-Feb-2026) |
Other details
| Brand | VISHAY |
| Part Number | AS1PM-M3/84A |
| Quantity | Each |
| Product Change Notice (113.42KB) EN | View or download |
| Technical Data Sheet (133.00B) EN | View or download |
