Description
Product Overview
The MC000054 is a 2-way 30A wire-to-board Terminal Block with tin-plated brass terminal, green polyamide 66 insulating body, nickel-plated steel cage clamp and screw. It has screw wire connection and through-hole right-angle block orientation.
- <gt/>2000MΩ at 500VDC Insulation resistance (Maximum)
- -40 to 105°C Operating temperature range
- Multicomp Pro products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
Applications
Industrial
Product details
| Pitch Spacing | 9.53mm |
| Wire Size AWG Min | 24AWG |
| Conductor Area CSA | - |
| Rated Current | 30A |
| Block Orientation | Through Hole Vertical |
| SVHC | No SVHC (04-Feb-2026) |
| No. of Positions | 2Ways |
| Wire Size AWG Max | 10AWG |
| Wire Connection Method | Screw |
| Rated Voltage | 600V |
| Product Range | - |
Other details
| Brand | MULTICOMP PRO |
| Part Number | MC000054 |
| Quantity | Each |
| Technical Data Sheet (291.29KB) EN | View or download |
