Description
Product Overview
The 250-403 is a 3-pole 4A grey wire-to-board Terminal Block with through-hole 45° block orientation and Push-in CAGE CLAMP® wire connection technology. It has tin-plated copper alloy contact with polyamide 66 insulation.
- Compact terminal strips with push-buttons
- Simple push-in termination for solid conductors
- Termination/removal of fine-stranded conductors via push-buttons
- 45° Conductor entry angle provides easy and space-saving wiring
- UL94V-0 Flammability rating
- -60 to 105°C Operating temperature range
Applications
Industrial
Product details
| Pitch Spacing | 2.5mm |
| Wire Size AWG Min | 24AWG |
| Conductor Area CSA | 0.5mm² |
| Rated Current | 4A |
| Block Orientation | Through Hole 45° |
| SVHC | No SVHC (04-Feb-2026) |
| No. of Positions | 3Ways |
| Wire Size AWG Max | 20AWG |
| Wire Connection Method | Push In |
| Rated Voltage | 160V |
| Product Range | - |
Other details
| Brand | WAGO |
| Part Number | 250-403. |
| Quantity | Each |
| Drawing (1.12MB) EN | View or download |
| Technical Data Sheet (175.73KB) EN | View or download |
