Description
Product Overview
The C3D10065A is a Zero Recovery® silicon carbide Schottky Diode features extremely fast switching, high-frequency operation and temperature-independent switching behaviour. It is used in switch mode power supplies, power factor correction and motor drives.
- 650V Schottky rectifier
- Zero forward recovery voltage
- Zero reverse recovery current
- Positive temperature coefficient on VF
- Replace bipolar with unipolar rectifiers
- Essentially no switching losses
- Higher efficiency
- Reduction of heat sink requirements
- Parallel devices without thermal runaway
Applications
Motor Drive & Control, Industrial
Product details
| Product Range | Z-Rec 650V |
| Repetitive Peak Reverse Voltage | 650V |
| Total Capacitive Charge | 24nC |
| No. of Pins | 2 Pin |
| Diode Mounting | Through Hole |
| Diode Configuration | Single |
| Average Forward Current | 14.5A |
| Diode Case Style | TO-220 |
| Operating Temperature Max | 175°C |
| Qualification | - |
Other details
| Brand | WOLFSPEED |
| Part Number | C3D10065A |
| Quantity | Each |
| Product Change Notice (285.59KB) EN | View or download |
| Technical Data Sheet (728.49KB) EN | View or download |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
