Product Overview
- 4:1 Input Range
- High Power Density
- High Efficiency - Up to 92%
- Remote On/Off
- 1600 VDC Isolation
Applications
Power Management, Industrial
Product details
| Power Supply Applications |
ITE |
| Input Ratio |
4:1 |
| No. of Outputs |
1 Output |
| Output Current - Output 1 |
8A |
| Output Current - Output 2 |
- |
| Isolation Voltage |
1.6kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
10.2mm |
| Input Voltage DC Min |
9V |
| Product Range |
JTL40 Series |
| DC / DC Converter Type |
DIP |
| Output Power Max |
40W |
| Output Voltage - Output 1 |
5V |
| Output Voltage - Output 2 |
- |
| Output Regulation |
Regulated |
| Input Voltage DC Nom |
24V |
| Width |
50.8mm |
| Depth |
50.8mm |
| Input Voltage DC Max |
36V |
| SVHC |
No SVHC (15-Jan-2018) |
Other details
| Brand |
XP POWER |
| Part Number |
JTL4024S05 |
| Quantity |
Each |
| Certificate of Conformity (143.06KB) EN |
View or download |
| Technical Data Sheet (244.58KB) EN |
View or download |
