Description
Product Overview
The A series Crystal Unit operating at a frequency range of 1 to 300MHz with ±50PPM maximum frequency tolerance at 25°C. It is suitable for microprocessor applications.
- Excellent clock signal generator for CPU's
- Wide frequency range
Applications
Computers & Computer Peripherals, Industrial
Product details
| Frequency Nom | 4MHz |
| Crystal Frequency | 4MHz |
| Frequency Stability + / - | 50ppm |
| Crystal Case / Package | Through Hole, 11mm x 4.65mm |
| Crystal Mounting | Through Hole |
| Operating Temperature Max | 70°C |
| Product Range | A |
| Frequency Tolerance + / - | 30ppm |
| Load Capacitance | 18pF |
| No. of Pins | 2Pins |
| Operating Temperature Min | -20°C |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | RALTRON |
| Part Number | A-4.000-18 |
| Quantity | Each |
| Technical Data Sheet (125.12KB) EN | View or download |
