Description
Product Overview
The KRM 04 is a 4-pole Screw Terminal Block, UL94V-2 flame-rated polyamide insulating body, pre-nickel/tin-plated CuZn clamp with wire protector. Upright, consecutive placement without loss of pitch.
- M3 Screw thread
- 0.5Nm Tightening torque
- 7 ±0.5mm Stripping length
- 1.3mm Creepage distance
- 1.3mm Clearance
- <gt/>10GΩ Insulation resistance
Applications
Industrial, Building Automation
Product details
| Pitch Spacing | 5mm |
| Wire Size AWG Min | - |
| Conductor Area CSA | 2.5mm² |
| Rated Current | 15A |
| Block Orientation | Through Hole Right Angle |
| SVHC | Lead (25-Jun-2025) |
| No. of Positions | 4Ways |
| Wire Size AWG Max | - |
| Wire Connection Method | Screw |
| Rated Voltage | 250V |
| Product Range | - |
Other details
| Brand | LUMBERG |
| Part Number | KRM 04 |
| Quantity | Each |
| Technical Data Sheet (153.27KB) EN | View or download |
| Product Change Notice (622.95KB) EN | View or download |
