Description
| Effect Types | Graphic, Transition, and Chroma Key |
| Switching Type | Pushbutton, T-Bar |
| Processing Resolution | UHD 4K at 60 |
| Color Processing | 4:4:4YUV |
| Latency | 3 Frames |
| Number of Video Input Sources | 5 |
| Video Inputs | 2x HDMI (2.0) 2x HDMI (1.3) 1x USB-A (2.0, UVC) |
| Input Video Format | HDMI (4:4:4 YUV) UHD 4K up to 60 fps 1080p up to 60 fps 1080i at 50 fps WUXGA+ (1680 x 1050) up to 60 fps WXGA+ (1440 x 900) up to 60 fps FWXGA (1366 x 768) up to 60 fps 1360 x 768 up to 60 fps SXVGA (1280 x 1024) up to 60 fps WXGA (1280 x 800) up to 60 fps 1280 x 768 up to 60 fps XGA (1024 x 768) up to 60 fps 720p at 50/60 fps USB-A (4:4:4 YUV) 1080p up to 60 fps 1080i at 50 fps WUXGA+ (1680 x 1050) up to 60 fps WXGA+ (1440 x 900) up to 60 fps FWXGA (1366 x 768) up to 60 fps 1360 x 768 up to 60 fps SXVGA (1280 x 1024) up to 60 fps WXGA (1280 x 800) up to 60 fps 1280 x 768 up to 60 fps XGA (1024 x 768) up to 60 fps 720p at 50/60 fps |
| Audio Inputs | 2x 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Mic/Line Female |
| Input Audio Format | Analog |
| Embedded Audio Input | HDMI USB-A |
| Video Output Channels | 4 |
| Video Outputs | 1x RJ45 (NDI) 1x USB-C (3.0) 1x HDMI (1.3) (Monitor) 1x HDMI (1.3) (Program) |
| Output Video Format | HDMI / RJ45 / USB-C (4:4:4 YUV) 1080p up to 60 fps 720p at 50/60 fps |
| Audio Outputs | 1x 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Female |
| Output Audio Format | Analog |
| Embedded Audio Output | RJ45 HDMI USB-C |
| Multiview Output | Yes |
| IP Video | 1920 x 1080 Encoding |
| Transport Protocols | NDI, RTMP, and SRT |
| Simultaneous Streams | 2 Streams |
| Compatible Services | Facebook Live and TikToK |
| Display Size | 5.5" |
| Processor | Not Specified by Manufacturer |
| Wireless | No |
| Power I/O | 1x Barrel Input |
| Power Consumption | Device: 12 VDC at 2 A (20 W) |
| Operating Conditions | 32 to 158°F / 0 to 70°C at 10 to 85% Humidity |
| Certifications | CE, FCC, RoHS |
| Dimensions | 10.3 x 5.7 x 1.9" / 26.1 x 14.4 x 4.9 cm |
| Weight | 4.4 lb / 2 kg |
| Package Weight | 3.455 lb |
| Box Dimensions (LxWxH) | 13.5 x 8.2 x 4.1" |
