| ₹ 99999999.0 includes GST and import duties. | |
| B2B customers can avail ₹ 15249999.85 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
| Effect Types | DVE, Transition, and Chroma Key |
| Audio Mixing | 16-Channel Mixing |
| Switching Type | Pushbutton, T-Bar, Touchscreen |
| Processing Resolution | UHD 4K |
| Number of Video Input Sources | 9 |
| Video Inputs | 4x BNC (3G-SDI) Female 2x HDMI (2.0) Female 2x HDMI (1.3) Female 1x USB-C (UVC) Female 1x USB-A (2.0) |
| Input Video Format | HDMI (4:4:4 YUV) UHD 4K at 30/50/60 fps 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50 fps 720p at 50/60 fps WUXGA+ (1680 x 1050) at 60 fps 1600 x 1050 at 60 fps WXGA+ (1440 x 900) at 60 fps FWXGA (1366 x 768) at 60 fps 1360 x 768 at 60 fps SXVGA (1280 x 1024) at 60 fps WXGA (1280 x 800) at 60 fps 1280 x 768 at 60 fps XGA (1024 x 768) at 60 fps |
| Audio Inputs | 2x 1/8" / 3.5 mm TRS Stereo Mic/Line Female |
| Input Audio Format | Analog PCM 2.0 |
| Embedded Audio Input | HDMI USB-C |
| Video Output Channels | 3 |
| Video Outputs | 1x BNC (3G-SDI) Female 2x HDMI Female 1x USB-C (3.0) Female |
| Output Video Format | HDMI / SDI / USB-C 1080p 24/30/50/60 fps 720p 50/60 fps |
| Audio Outputs | 1x 1/8" / 3.5 mm TRS Stereo Line Female |
| Output Audio Format | Analog PCM 2.0 |
| Embedded Audio Output | HDMI SDI USB-C |
| Multiview Output | Yes |
| Other I/O | 1x RJ45 LAN Input/Output (Shared Control, Streaming) |
| Transport Protocols | NDI, RTMP, and SRT |
| Simultaneous Streams | 2 Streams |
| Compatible Services | Facebook Live, Instagram, TikToK, Twitch, and YouTube Live |
| Recording Media | 1x SD (Unspecified Type) |
| Display Size | 10.1" |
| Processor | Not Specified by Manufacturer |
| Wireless | No |
| Power I/O | 1x Barrel (12 VDC at 2 A) Input |
| Power Consumption | 20 W |
| Operating Conditions | 32 to 158°F / 0 to 70°C at 10 to 85% Humidity |
| Dimensions | 9.8 x 8.1 x 2.5" / 250 x 206 x 63 mm |
| Weight | 4.6 lb / 2.1 kg |
| Package Weight | 7.5 lb |
| Box Dimensions (LxWxH) | 15.2 x 11 x 4.1" |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 97999999.02 |
| 3-5 | ₹ 96999999.03 |
| 5-10 | ₹ 94999999.05 |
| 10+ | ₹ 92999999.07 |
Bulk discount will be automatically applied during checkout based on quantity.
