Description
| Available M/E Layers | 5 M/E |
| Effect Types | Graphic, Transition, Chroma Key, Luma Key |
| Downstream Keys | 2x Overlay |
| Switching Type | Pushbutton, Software |
| Processing Resolution | 1080p at 23.98/24/25/29.97/30/50/59.94/60 |
| Color Processing | YUV |
| Number of Video Input Sources | 4 |
| Video Inputs | 4x HDMI |
| Input Video Format | HDMI 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/60 fps |
| Audio Inputs | 2x 1/8" / 3.5 mm TRS Stereo Female |
| Embedded Audio Input | HDMI |
| Video Output Channels | 3 |
| Video Outputs | 1x HDMI (Program) 1x HDMI 1x USB-A (3.1) |
| Output Video Format | HDMI 1080p at 24/25/30/50/60 fps 1080i at 50/60 fps USB-A 1080p up to 60 fps |
| Audio Outputs | 1x 1/8" / 3.5 mm TRS Stereo |
| Embedded Audio Output | HDMI USB-A |
| Multiview Output | 4-Way Multiview |
| Other I/O | 1x RJ45 LAN 1x USB-A 2.0 Input |
| IP Video | 1920 x 1080 at 60p Encoding |
| IP Audio | Encoding |
| Display Size | 4.5" |
| Processor | Not Specified by Manufacturer |
| Wireless | No |
| Power I/O | 1x Barrel (7 to 24 VDC at 2 A) Input |
| Power Consumption | 10 W |
| Operating Conditions | -4 to 122°F / -20 to 50°C |
| Storage Conditions | -4 to 140°F / -20 to 60°C |
| Dimensions | 7.4 x 4.3 x 1.9" / 189 x 109 x 49 mm |
| Weight | 0.9 lb / 393 g |
| Package Weight | 1.79 lb |
| Box Dimensions (LxWxH) | 11.2 x 6.1 x 3.1" |
