Description
Designed to handle intensive tasks such as direct video editing, the Lockerstor 6 Gen2+ 6-Bay NAS Enclosure from Asustor offers the speed and capabilities to take on almost any project. In addition to featuring six 3.5"/2.5" SATA drive bays, this high-performance network storage enclosure has four M.2 2280 NVMe PCIe 3.0 SSD slots that may be configured for cache or storage. You can also mix and match M.2 configurations and set up RAID modes depending on your needs. The dual 5G Ethernet ports support SMB multichannel technology, which allows you to combine their throughput to reach 10G speeds with compatible devices, giving you the bandwidth to share massive files with your team. Powered by a 2.0 GHz Intel Celeron N5105 quad-core processor with 8GB of DDR4-2933 memory, the Lockerstor 6 Gen2+ can deliver up to 590 MB/s read and 562 MB/s write speeds in RAID 5 configuration.
Install a 10G Ethernet network adapter into the PCIe 3.0 slot for even greater performance. Please note that the PCIe slot is occupied by an M.2 daughter board with all four of the system's M.2 SSD slots. Installing an expansion card requires its removal. The two memory slots support up to 16GB total. Other features include two USB-A 3.2 Gen 2 ports that can transfer data at up to 10 Gb/s with compatible devices.
| RAID | Yes: Supported RAID Modes: 0 / 1 / 5 / 6 / 10 / JBOD |
| Number of Bays | 4x M.2 (2280) NVMe 6x 2.5"/3.5" SATA (Hot-Swap) |
| Inputs/Outputs | 2x USB-A 3.1/3.2 Gen 2 1x USB-A 2.0 1x HDMI 2.0b 2x RJ45 5GbE |
| CPU | Quad-Core: 2 to 2.9 GHz |
| Processor | Intel Celeron N5105 |
| GPU | Intel UHD Graphics |
| Memory | 8 GB DDR4 |
| RAM Configuration / Capacity | 1x User-Replaceable 8 GB Module / 2 Slots Supporting up to 16 GB (SO-DIMM) |
| RAID | Yes: Supported RAID Modes: 0 / 1 / 5 / 6 / 10 / JBOD |
| Number of Bays | 4x M.2 (2280) NVMe 6x 2.5"/3.5" SATA (Hot-Swap) |
| Inputs/Outputs | 2x USB-A 3.1/3.2 Gen 2 1x USB-A 2.0 1x HDMI 2.0b 2x RJ45 5GbE |
| Media Card Slots | No |
| PCI Expansion | 1x PCIe 3.0 x1 |
| Link Aggregation and Failover Support | Yes |
| iSCSI Support | Yes: 256 LUN / 256 Target |
| Installed Operating System | No |
| OS Compatibility | Windows 10 or Later Windows Server 2016 to 2022 macOS UNIX Linux FreeBSD |
| Mobile App Compatible | Yes: Android & iOS |
| Encryption | Yes, 256-Bit AES |
| Security Features | No |
| Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Consumption | 48.5 W (Typical) 27.7 W (Idle) 0.81 W (Standby) |
| PSU | 1 x 250 W |
| Operating Conditions | 32 to 104°F / 0 to 40°C at 5 to 95% Humidity |
| Storage Conditions | -20 to 70°F / -29 to 21°C |
| Certifications | BIS, BSMI, C-Tick, CCC, CE, FCC, Kcc, UKCA, VCCI |
| Cooling | 1x 120 mm Fan |
| Noise Level | 18.1 dBA |
| Dimensions | 9.2 x 9.1 x 7.3" / 233.7 x 231.1 x 185.4 mm |
| Weight | 9.7 lb / 4.4 kg (without Drives) |
| Package Weight | 12.155 lb |
| Box Dimensions (LxWxH) | 13.4 x 12.7 x 12.1" |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 150047.8 |
| 3-5 | ₹ 148516.7 |
| 5-10 | ₹ 145454.5 |
| 10+ | ₹ 142392.3 |
Bulk discount will be automatically applied during checkout based on quantity.
