| ₹ 13068090.0 includes GST and import duties. | |
| B2B customers can avail ₹ 1992883.73 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
The compact Codex Compact Drive 1TB from ARRI is a durable, industrial-style SSD compatible with the ALEXA Mini LF or ALEXA 35 camera. The drive's full 1TB capacity is available for recording both ARRIRAW and ProRes without needing to reformat or switch drives.
The compact drive works without a driver or license and features a sustained write speed of up to 8 Gb/s. Using a Compact Drive Adapter allows you to mount the drives on an existing SXR Capture Drive Dock (Mac only) or any other SXR Capture Drive hardware from Codex.
The compact Codex Compact Drive 2TB from ARRI is a fast, durable drive compatible with ALEXA 35 and ALEXA Mini LF cameras. This 2TB drive provides a usable capacity of 1920GB and a write speed of up to 16 Gb/s (~2000 MB/s) for unlimited recording. A yellow ring offers easy color coding when used with drives of other capacities.
ript>| Lens Mount | Interchangeable Mount with Included ARRI LPL/ARRI PL |
| Image Sensor | Super35 |
| Effective Sensor Resolution | 14.58 Megapixel (4608 x 3164) |
| Image Stabilization | No |
| ISO/Gain Sensitivity | Native: 160 to 6400 |
| Max Recording Modes | Up to 4.6K from 0.75 to 75 fps |
| Media/Memory Card Slot | Single Slot: Codex Compact Drive |
| Mobile App Compatible | Yes: Android & iOS |
| Lens Mount | Interchangeable Mount with Included ARRI LPL/ARRI PL |
| Lens Communication | Yes |
| Image Sensor | 27.99 x 19.22 mm (Super35) CMOS |
| Sensor Resolution | 14.58 Megapixel (4608 x 3164) |
| Image Stabilization | No |
| Built-In ND Filter | Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters |
| Built-In CC Filter | No |
| Internal Filter Holder | No |
| Capture Type | Video Only |
| Shutter Type | Electronic Rolling Shutter |
| Shutter Speed | 1/8000 to 1 Second |
| Shutter Angle | 5 to 356° |
| ISO/Gain Sensitivity | Native: 160 to 6400 |
| Advertised Dynamic Range | 17 Stops |
| White Balance | Range: 2000 to 11,000K |
| Focus Mode | Manual Focus Only |
| Internal Recording | ARRIRAW 4608 x 3164 from 0.75 to 75 fps 3072 x 3072 from 0.75 to 100 fps* 3328 x 2790 from 0.75 to 100 fps* 4608 x 2592 from 0.75 to 75 fps 4096 x 2304 from 0.75 to 120 fps* 4096 x 2048 from 0.75 to 120 fps* MXF/ProRes 422 HQ/ProRes 4444/ProRes 4444XQ 12-Bit 4608 x 3164 from 0.75 to 59.94 fps 3072 x 3072 from 0.75 to 90 fps* 3328 x 2790 from 0.75 to 75 fps* 4096 x 2304 from 0.75 to 100 fps* 3840 x 2160 from 0.75 to 120 fps* 4096 x 2048 from 0.75 to 120 fps* 2048 x 1152 from 0.75 to 120 fps* *Sensor Crops During Recording |
| Fast-/Slow-Motion Support | Yes |
| Gamma Curve | ARRI Log C4, Rec 2100 HLG, Rec 2100 PQ, Rec709, Rec2020 |
| Built-In Microphone | Stereo |
| Audio Recording | 4-Channel, 24-Bit at 48 kHz via LPCM Audio |
| Media/Memory Card Slot | Single Slot: Codex Compact Drive |
| Internal Storage | No |
| Video I/O | 1x BNC (12G-SDI) Output 1x BNC (12G-SDI) Input/Output |
| Audio I/O | 1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output 1x 6-Pin LEMO Line Input |
| Power I/O | 1x LEMO 8-Pin (20.5 to 33.6VDC) Input |
| Other I/O | 2x CoaXPress Viewfinder 1x LEMO 4-Pin Control Input/Output 1x LEMO 4-Pin (Serial) Data Input/Output 1x LEMO 5-Pin (Timecode) Input/Output 1x LEMO 10-Pin (Ethernet) Control 1x BNC (Sync) Input/Output 1x USB-C Data Input/Output 1x Pogo 5-Pin 1x pogo 18-Pin |
| Wireless | 802.11b/g Wi-Fi |
| Mobile App Compatible | Yes: Android & iOS |
| Global Positioning (GPS, GLONASS, etc.) | No |
| Display Type | Primary Monitor: Included External 4" Non-Touchscreen LCD Status Display: Fixed Non-Touchscreen LCD |
| Resolution | Primary Monitor: 800 x 400 |
| Type | Removable Electronic (OLED) |
| Resolution | 1920 x 1080 |
| Power Consumption | 90 W |
| Operating Conditions | -4 to 113°F / -20 to 45°C |
| Storage Conditions | -22 to 158°F / -30 to 70°C |
| Tripod Mount | 1/4"-20 Female 3/8"-16 Female |
| Netflix Approved | Yes |
| Materials | Aluminum |
| Dimensions (W x H x D) | 8 x 6 x 5.8" / 203.2 x 152.4 x 147.3 mm |
| Weight | 6 lb / 2.9 kg (With Antennae, Lens Mount Adapter) |
| Package Weight | 30.5 lb |
| Box Dimensions (LxWxH) | 24.38 x 20.5 x 18.38" |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 12806728.2 |
| 3-5 | ₹ 12676047.3 |
| 5-10 | ₹ 12414685.5 |
| 10+ | ₹ 12153323.7 |
Bulk discount will be automatically applied during checkout based on quantity.
