Description
Synology UC3400 Overview
- 1Description
- 2Reliability and High Availability
- 3Active-Active SAN with Enterprise-Class Performance
- 4Virtualization Ready
- 5Flexible Network Options
- 6Built-In Data Protection and Security
- 7Storage Expansion
- 8Performance Backed by Synology Drives
- 9Limited 5-Year Warranty
- 10Synology Replacement Service (SRS)
Designed for high-availability SAN environments, the UC3400 12-Bay Active-Active SAN Enclosure from Synology is a 2 RU rackmount server with an active-active architecture that ensures uninterrupted block storage services, while providing resilient data protection and a simplified management interface. With its ability to maximize service uptime for critical services, the UC3400 is ideal for organizations that require a mission-critical storage system. This unit has 12 drive bays, each of which natively supports 3.5" SAS hard drives and 2.5" SAS SSDs. Should users need to expand the overall capacity of their UC3400, two mini-SAS ports can each accommodate one RXD1219sas expansion unit. Between the NAS and two expansion units, up to 36 drives are supported.
The UC3400 is powered by dual 2.1 GHz Intel Xeon D-1541 8-Core processors (one per controller) and 16GB of DDR4 ECC RAM (8GB per controller) that can be upgraded to a total of 128GB (64GB per controller). Each controller has four DIMM slots and each slot supports up to 16GB. Network connectivity is achieved via the two 10 Gigabit Ethernet ports (one per controller) or four Gigabit Ethernet ports (two per controller) with failover support, which helps to provide redundancy in the case that a LAN connection malfunction occurs on one port. In addition, link aggregation helps to increase connection speeds beyond the limits of a single network port or cable. If you're looking to expand this NAS, there are two PCIe Gen 3.0 x8/x8 slots (one per controller) that support 10/25GbE network cards or a 16 Gigabit Fiber Channel host bust adapter card.
The UC3400 runs on the DiskStation Manager (DSM) operating system, which helps simplify managing your NAS, as well as accessing and sharing data. A variety of RAID modes are supported, which help provide users with data redundancy, speed, or a combination of both. Supported RAID modes include RAID 0, 1, 5, 6, 10, Basic, and F1. For those who do not require a RAID, JBOD is also available, allowing each drive bay to be individually utilized.
Synology has engineered the UC3400 to be energy efficient. Not only does it offer four 60 x 60mm fans (two per controller) to help keep the system running cool, the server also supports numerous scheduled power on/off cycles and hard drive hibernation to further minimize power consumption and operation expenses. The UC3400 operates using redundant 500W power supplies on 100-240 VAC at 50/60 Hz and includes an accessory pack and two AC power cords. Protection is provided by a limited 5-year warranty.
- Full certification for VMware, vSphere, Microsoft Hyper-V, Citrix XenServer, and OpenStack environments.
- Support for Windows Offloaded Data Transfer (ODX), VMware vSphere Storage APIs Array Integration (VAAI), and ALUA ensures optimized and efficient storage operations.
- OpenStack Cinder support enables UC3400 to become a block-based storage component.
Snapshot Replication
Built-in software offers application-aware snapshot protection and instant recovery of virtual machines in iSCSI LUNs in the event of a disaster.
Self-Encrypting Drive Support
Native support for self-encrypting drives (SEDs) provides hardware-level encryption for mission-critical and sensitive data at rest.
In the Box
- Synology UC3400 12-Bay Active-Active SAN Enclosure with Dual Controllers
- Accessory Pack
- 2 x AC Power Cords
- Limited 5-Year Manufacturer Warranty
Not in the Box
- Essential Rack Accessories (Not Included)
- Description
- Reliability and High Availability
- Active-Active SAN with Enterprise-Class Performance
- Virtualization Ready
- Flexible Network Options
- Built-In Data Protection and Security
- Storage Expansion
- Performance Backed by Synology Drives
- Limited 5-Year Warranty
- Synology Replacement Service (SRS)
Synology UC3400 Specs
| Number of Bays |
12x 2.5"/3.5"
|
| Inputs/Outputs |
2x RJ45 10GbE
4x RJ45 Gigabit Ethernet 2x Mini SAS (Unspecified) |
| Compatible Drive Interface |
SAS-3
|
| RAID |
RAID 0/1/5/6/10/Basic/F1
|
| CPU |
8-Core: 2.1 to 2.7 GHz
|
| Processor |
2x Intel Xeon D-1541
|
| Total Installed Memory |
16 GB ECC DDR4
|
| User-Replaceable Memory |
2x 8 GB
|
| Total Memory Slots |
8x DIMM
|
| Maximum Memory Capacity |
128 GB
|
| Number of Bays |
12x 2.5"/3.5"
|
| Inputs/Outputs |
2x RJ45 10GbE
4x RJ45 Gigabit Ethernet 2x Mini SAS (Unspecified) |
| Compatible Drive Interface |
SAS-3
|
| Media Card Slots |
No
|
| Form Factor |
Rackmount (2 RU)
|
| RAID |
RAID 0/1/5/6/10/Basic/F1
|
| Hot-Swap Support |
Yes
|
| PCI Expansion |
2x PCIe 3.0 x8 (x8 Electrical)
|
| Supported Protocols |
SNMP
SSH Telnet iSCSI |
| iSCSI LUN |
128
|
| iSCSI Target |
128
|
| Max User Accounts |
65
|
| Max Volume Number |
32
|
| Installed Operating System |
No
|
| Mobile App Compatible |
Yes
|
| Supported Browsers |
Chrome, Edge, Firefox, Safari
|
| Supported Languages |
Brazilian Portuguese
Czech Danish Dutch English French German Hungarian Italian Japanese Korean Norwegian Polish Portuguese Russian Simplified Chinese Spanish Swedish Thai Traditional Chinese Turkish |
| Encryption |
AES-NI (Hardware-Based)
|
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| Power Source |
Internal Power Supply
|
| Power Consumption |
239.25 W (Typical)
|
| PSU Wattage |
2 x 500 W (Supports Redundancy)
|
| Operating Temperature |
32 to 95°F / 0 to 35°C
|
| Operating Humidity |
5 to 95%
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Certifications |
CE, FCC, BSMI, VCCI, RCM, UKCA, Kcc, EAC, RoHS
|
| Color |
Black / Gray
|
| Status Monitoring |
LED Indicator
|
| Cooling |
4x 60 mm Fans
|
| Noise Level |
51.3 dBA
|
| Built-In Speakers |
No
|
| Dimensions |
28.5 x 19 x 3.5" / 724 x 482 x 88 mm
|
| Weight |
43.4 lb / 19.7 kg
|
| Package Weight |
54 lb
|
| Box Dimensions (LxWxH) |
32.63 x 23.75 x 9.38"
|
