Description
SWIT CURVE500 Overview
- 1Description
- 2Automatic Channel Selection
- 3500' Range
- 4Use Multiple Sets
By Photo's
Mary Latvis
Transmit up to 1080p60 video with the CURVE500 HDMI Wireless Video Transmission System from SWIT. This transmitter and receiver set features robust cross-wall performance at a line-of-sight range of up to 500'. The receiver sports on HDMI input and one HDMI loop output while the receiver has two HDMI loop outputs. Both the transmitter and receiver can be powered using L-Series batteries or via a DC barrel input.
Automatic Channel Selection
This set uses SWIT's KUWI wireless technology with license-free 5.1-5.9 GHz bands and dynamic frequency selection (DFS) to automatically select the clearest channel
500' Range
Works at line-of-sight ranges of up to 500' and features robust cross-wall performance
Use Multiple Sets
Supports up to three sets in one location
In the Box
- SWIT CURVE500 HDMI Wireless Video Transmission System
- Transmitter
- Receiver
- 4 x Antenna
- D-Tap to Locking Barrel Cable
- AC Adapter
Table of Contents
- Description
- Automatic Channel Selection
- 500' Range
- Use Multiple Sets
SWIT CURVE500 Specs
| Antenna I/O | Transmitter: 2 x RP-SMA Receiver: 2 x RP-SMA |
| Video I/O | Transmitter: 1 x HDMI Input Transmitter: 1 x HDMI Loop Output Receiver: 2 x HDMI Output |
| HDCP Support | Not Specified by Manufacturer |
| Embedded Audio | HDMI: 2-Channel |
| Audio I/O | None |
| Power | Transmitter: 1 x Barrel 5.5 mm Input Receiver: 1 x Barrel 5.5 mm Input |
| Other I/O | Transmitter: 1 x USB-B Input Receiver: 1 x USB-B Input |
| Encryption | 128-Bit AES |
Wireless
| Wireless Range | 492.1' / 150 m |
| Frequency Range | 5180 to 5220 MHz 5760 to 5820 MHz |
| Wi-Fi | None |
| Bluetooth | None |
Format Support
| Video Format | HDMI 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 23.98 1080i: 60/59.94/50 720p: 60/59.94/50 |
| Audio Format | Not Specified by Manufacturer |
| Timecode Support | No |
Power
| DC Input Power | 7 to 17 VDC |
| Battery Type | Transmitter: 1 x L-Series Receiver: 1 x L-Series |
| Power Consumption | Transmitter: 7.5 W Receiver: 7 W |
Mounting
| Mounting | 1 x 1/4"-20 Female |
Environmental
| IP Rating | None |
| Certifications | FCC *as per Manufacturer |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
General
| Material of Construction | Metal |
| Dimensions | Transmitter: 4.5 x 2.74 x 1.1" / 114.18 x 69.55 x 28 mm Receiver: 4.5 x 2.74 x 1.1" / 114.18 x 69.55 x 28 mm |
| Weight | Transmitter: 7.0 oz / 198.6 g, Including Antenna Receiver: 7.1 oz / 201 g, Including Antenna |
Packaging Info
| Package Weight | 2.125 lb |
| Box Dimensions (LxWxH) | 9.9 x 7.7 x 3.4" |
