| ₹ 101.14 includes GST and import duties. | |
| B2B customers can avail ₹ 15.42 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The PRL1632-R100-F-T5 is a 0.1R 1W SMD current sense Chip Resistor with 1206 case, thin film element and long side terminal. The distinctive structure that encourages heat dissipation and radiation limits the rise of the surface temperature, allows the realization of smaller sizes and reduces influence of heat on surrounding components.
- Low ESL contributes to less noise
- Withstands temperature cycles very well
- -55 to 125�C Operating temperature range
Applications
Computers & Computer Peripherals, Power Management, Automotive, Industrial
Product details
| Resistance | 0.1ohm |
| Resistor Case Style | 1206 [3216 Metric] |
| Resistor Element Type | Thin Film |
| Resistance Tolerance | � 1% |
| Product Range | PRL Series |
| Automotive Qualification Standard | - |
| Temperature Coefficient | � 50ppm/�C |
| Power Rating | 1W |
| Packaging | Cut Tape |
Other details
| Brand | SUSUMU |
| Part Number | PRL1632-R100-F-T5 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 99.12 |
| 3-5 | ₹ 98.11 |
| 5-10 | ₹ 96.08 |
| 10+ | ₹ 94.06 |
Bulk discount will be automatically applied during checkout based on quantity.
