Description
Supermicro SYS-E300-8D Overview
Supermicro's smal Xeon Server Box is based on Intel Xeon D SoC. It is well-suited for embedded networking applications, network security appliance, FireWall applications, virtualization server
Key Features
- Embedded networking applications
- Network security appliance
- FireWall applications
- Virtualization server
UPC: 672042242344
In the Box
- Supermicro E300-8D SuperServer with Intel Xeon Processor D-1518 (Black)
- Supermicro SuperServer E300-8D
- Power adapter
Supermicro SYS-E300-8D Specs
General
Type | Server |
Product Form Factor | Mini-1U |
Server Scalability | 1-way |
Internal Bays Qty | 1 |
Color | Black |
Processor / Chipset
CPU | Intel Xeon D-1518 / 2.2 GHz |
Number of Cores | Quad-Core |
CPU Qty | 1 |
Max CPU Qty | 1 |
Cache Memory
Installed Size | 6 MB |
Cache Per Processor | 6 MB |
RAM
Installed Size | 0 GB / 128 GB (max) |
Technology | DDR4 SDRAM |
Form Factor | DIMM 288-pin |
Slots | 4 (total) / 4 (empty) |
Features | Unbuffered, registered |
RAM Supported | 128 GB registered - ECC 64 GB unbuffered - ECC 64 GB unbuffered - non-ECC |
Hard Drive
Type | No HDD |
Storage Controller
Type | 1 x SATA |
Controller Interface Type | SATA 6Gb/s |
Channel Qty | 4 |
Optical Storage
Type | No optical drive |
Monitor
Monitor Type | None. |
Graphics Controller
Graphics Processor | ASPEED AST2400 |
Video Interfaces | VGA |
Networking
Ethernet Ports | 6 x Gigabit Ethernet, 2 x SFP+ |
Ethernet Controller | Intel I350-AM4, I210 |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
Remote Management Protocol | IPMI 2.0 |
Features | KVM over IP support |
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x internal 2.5" |
Slots | 4 (total) / 4 (free) x DIMM 288-pin 1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile 1 (total) / 1 (free) x M.2 Card - 22110 1 (total) / 1 (free) x Mini PCIe |
Interfaces | 6 x LAN (Gigabit Ethernet) - RJ-45 1 x management - RJ-45 2 x USB 3.0 1 x VGA 2 x LAN (10Gigabit Ethernet) (SFP+) - SFP+ |
Miscellaneous
Compliant Standards | RoHS, ACPI 5.0 |
Power
Device Type | Power adapter |
Power Provided | 60 Watt |
Operating System / Software
OS Provided | No operating system |
Manufacturer Warranty
Service & Support | Limited warranty - labor - 3 years Limited warranty - parts - 1 year |
Dimensions & Weight
Width | 10 in |
Depth | 8.9 in |
Height | 1.7 in |
Weight | 3.44 lbs |
Environmental Parameters
Min Operating Temperature | 32 °F |
Max Operating Temperature | 104 °F |
Humidity Range Operating | 8 - 90% (non-condensing) |
Packaging Info
Package Weight | 7.05 lb |
Box Dimensions (LxWxH) | 15 x 11.2 x 5.5" |
