Description
This is a Triac, 600 V, 4 A, TO-220FPAB, 35 mA, 1.3 V product from STMICROELECTRONICS with the model number T435T-600FP
Product details
| Peak Repetitive Off-State Voltage, Vdrm | 600V |
| On State RMS Current IT(rms) | 4A |
| Triac Case Style | TO-220FPAB |
| Gate Trigger Current Max (QI), Igt | 35mA |
| Gate Trigger Voltage Max Vgt | 1.3V |
| Peak Gate Power | - |
| Peak Non Rep Surge Current Itsm 50Hz | 30A |
| Holding Current Max Ih | 35mA |
| No. of Pins | 3Pins |
| Operating Temperature Max | 125°C |
| Product Range | Snubberless T Series |
Other details
| Brand | STMICROELECTRONICS |
| Part Number | T435T-600FP |
| Quantity | Each |
| Technical Data Sheet EN |  |
