Description
The T410-600T is a 3-pin Triac is suitable for use on AC inductive loads, applications using universal motors, electro valves, kitchen aid equipment, power tools, dishwashers. The T series is the latest addition to Snubberless Triacs and provides enhanced commutation for a given current rating. Immunity is also improved up to 5 times for a given current rating.
- 10mA Sensitivity
Applications
Motor Drive & Control, Consumer Electronics, Power Management
Product details
| Peak Repetitive Off-State Voltage, Vdrm | 600V |
| On State RMS Current IT(rms) | 4A |
| Operating Temperature Max | 125°C |
| Gate Trigger Current Max (QI), Igt | 10mA |
| No. of Pins | 3Pins |
| Gate Trigger Voltage Max Vgt | 1.5V |
| Product Range | - |
| Holding Current Max Ih | 15mA |
| Peak Non Rep Surge Current Itsm 50Hz | 30A |
| Triac Case Style | TO-220AB |
| Peak Gate Power | 1W |
| MSL | - |
Other details
| Brand | STMICROELECTRONICS |
| Part Number | T410-600T |
| Quantity | Each |
| Technical Data Sheet EN |  |
