Stmicroelectronics STM32F373CCT6 STM32F373CCT6 ARM MCU 16 Bit Sigma Delta ADC STM32 Family STM32F3 Series Microcontrollers Cortex-M4F

The STM32F373CCT6 is a 32-bit 256kB flash ARM®Cortex® -M4 Microcontroller Unit offers digital signal processing (DSP) and floating point unit (FPU). It offers one fast 12-bit ADC, three 16-bit sigma delta ADCs and two comparators, two DACs, a low-power RTC and 9 general-purpose 16-bit timers, two general-purpose 32-bit timers and three basic timers. It features standard and advanced communication interfaces two I²Cs, three SPIs, all with muxed I²Ss, three USARTs, CAN and USB. It incorporates high-speed embedded memories and an extensive range of enhanced I/Os and peripherals connected to two APB buses.

• CRC calculation unit
• Reset and power management - Power-ON/power DOWN reset (POR/PDR)
• Programmable voltage detector
• Low-power - Sleep, stop and standby
• VBAT supply for RTC and backup registers
• 12-channel DMA controller
• Independent and system watchdog timers
• SysTick timer - 24-bit down counter
• Calendar RTC with alarm and periodic wakeup from stop/standby
• Serial wire devices, JTAG, Cortex®-M4 ETM
• 96-bit Unique ID

Applications

Computers & Computer Peripherals, Communications & Networking, Security

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	STMICROELECTRONICS
Part Number	STM32F373CCT6
Quantity	Each
Technical Data Sheet EN
CAD CadSoft_EAGLE EN
Product Change Notice EN
