Description
The Trisil SMP80MC series micro capacitance Transient Surge Arrestors Diode designed for the protection of high debit rate communication equipment on CPE side. Its micro capacitance avoids any distortion of the signal and is compatible with digital transmission like ADSL2 and ADSL2+. It is not subject to ageing and provides a fail safe mode in short circuit for a better protection.
- Bidirectional crowbar protection
- 120 to 320V Voltage range
- Low VBO/VR ratio
- 12pF @ 50V Micro capacitance
- 2µA Maximum low leakage current IR
- 150mA Minimum holding current IH
- 80A (10/1000µs) Repetitive peak pulse current IPP
Communications & Networking, Industrial
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.Other details
| Brand | STMICROELECTRONICS |
| Part Number | SMP80MC-270 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
