Description
Low quiescent current, low-noise regulator with soft-start suitable for use in infotainment and cluster, ADAS, telematics and body electronics applications.
- AEC-Q100 qualified
- Ultra low-dropout voltage and very low quiescent current
- Very low-noise with no bypass capacitor
- Output voltage tolerance: ±2% at 25°C
- 1A guaranteed output current
- Logic-controlled electronic shutdown
- Power Good function
- Stable with ceramic capacitors COUT = 1 µF
- Internal current and thermal limit
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Output Type: Adjustable |
| Input Voltage Min: 1.5V |
| Input Voltage Max: 5.5V |
| No. of Outputs: 1Outputs |
| Output Voltage Nom: - |
| Output Voltage Min: 800mV |
| Output Voltage Max: 4.5V |
| Polarity: Positive Output |
| Output Current Max: 1A |
| Dropout Voltage Typ @ Current: 200mV |
| IC Mounting: Surface Mount |
| IC Case / Package: WDFN |
| No. of Pins: 6Pins |
| Operating Temperature Min: -40°C |
| Operating Temperature Max: 125°C |
| Product Range: Adj 1A LDO Voltage Regulators |
| MSL: MSL 3 - 168 hours |
Other details
| Brand | STMICROELECTRONICS |
| Part Number | LD49100PURY |
| Quantity | Each |
| Technical Data Sheet EN |  |
