Low quiescent current, low-noise regulator with soft-start suitable for use in infotainment and cluster, ADAS, telematics and body electronics applications.
- AEC-Q100 qualified
- Ultra low-dropout voltage and very low quiescent current
- Very low-noise with no bypass capacitor
- Output voltage tolerance: ±2% at 25°C
- 1A guaranteed output current
- Logic-controlled electronic shutdown
- Power Good function
- Stable with ceramic capacitors COUT = 1 µF
- Internal current and thermal limit
Footnotes Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Other details
| Brand |
STMICROELECTRONICS |
| Part Number |
LD49100PU33RY |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
| Product Change Notice EN |
|
