Description
The IIS2DLPC is an ultra-low-power high-performance three-axis linear accelerometer with digital I²C/SPI output interface which leverages on the robust and mature manufacturing processes already used for the production of micromachined accelerometers. The IIS2DLPC has user-selectable full scales of ±2g/±4g/±8g/±16g and is capable of measuring accelerations with output data rates from 1.6 Hz to 1600 Hz.
- ±2g/±4g/±8g/±16g full scale
- Multiple operating modes reconfigurable on the fly: from ultra-low-power to high-performance highresolution mode
- Ultra-low power consumption: 50nA in power-down mode, below 1µA in active low-power mode, 120µA in high-performance mode
- Output data rates from 1.6Hz to 1600Hz; bandwidth up to 800Hz
- Single data conversion on demand
- Very low noise: down to 90µg/�Hz
- 32level FIFO and 2 independent programmable interrupts
- High-speed I2C/SPI digital output interface
- Supply voltage, 1.62V to 3.6V
- Embedded temperature sensor
- Self-test
- 10000g high shock survivability
IoT (Internet of Things), Industrial, Power Management
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.Other details
| Brand | STMICROELECTRONICS |
| Part Number | IIS2DLPCTR |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
