Description
The BAT48 is a surface mount small signal Schottky Diode features low leakage current losses, negligible switching losses, very low turn-on voltage and extremely fast switching. Suitable for general purposes.
- Low forward and reverse recovery times
- Low capacitance
- 40V Breakdown reverse voltage
Applications
Signal Processing, RF Communications
Product details
| Forward Voltage VF Max | 400mV |
| Operating Temperature Max | 125°C |
| No. of Pins | 2Pins |
| Forward Current If(AV) | 350mA |
| Product Range | BAT48 Series |
| Automotive Qualification Standard | - |
| Diode Configuration | Single |
| Repetitive Reverse Voltage Vrrm Max | 40V |
| Packaging | Each |
| Diode Case Style | DO-35 |
| Forward Surge Current Ifsm Max | 7.5A |
Other details
| Brand | STMICROELECTRONICS |
| Part Number | BAT48 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
