Description
StarTech SV231DPDDUA Overview
The 2-Port Dual DisplayPort USB KVM Switch with Audio & USB 2.0 Hub from StarTech combines next generation digital display standards with seamless KVM control, allowing you to switch between 2 dual head or twin DisplayPort systems. It is also ideal for systems with a single DisplayPort output and a second video source such as DVI or HDMI using a low-cost accessory adapter.
Delivering multi-computer control for high-res multimedia applications, the dual view KVM supports resolutions of 2560 x 1600 (@ 60 Hz) with DisplayPort HD audio as well as 2-channel analog stereo audio and microphone input. Suitable for high-quality static imaging, such as medical applications (MRI, X-ray and more), a maximum resolution of 3840 x 2400 is supported at lower refresh rates. Native dual DisplayPort connections - no adapter required
Supports 2560 x 1600 @ 60 Hz resolutions; beyond 1080p
Maximum resolutions of 3840 x 2400 at lower refresh rates
7.1 channel high definition digital audio supported via the DisplayPort interface
0.14" (3.5mm) 2-channel stereo audio and microphone
Integrated 2-port USB 2.0 hub provides peripheral sharing to eliminate the expense of duplicate devices (printers, scanners and more)
No driver or software installation required
OS independent
Hotkey and push button switching
Full plug-and-play support with USB console interfaces
User-defined scan time intervals
USB 2.0 hub and audio can be switched independently
Supports hot-plug, un-plug and link status-failure detection
Supports DDC2B for monitor detection
Small form factor design with rear connection ports
Versatile KVM solution works well with Mini-DisplayPort, DisplayPort to DVI or HDMI adapters; perfect for Dual DisplayPort or DisplayPort + DVI or HDMI video output, including MacBook connectivity
VESA and CEA compliant
Applications
Multimedia design, multimedia post-production and video editing using Mac or PC computers
High resolution medical imaging and health care display, such as MRI and X-ray display
Stock trading stations with dual displays
Great for PC test/burn-in computer control, saving desk space required for multiple monitors, keyboards and mice
Dual system control for a single workstation increasing productivity in the office
Leverage DisplayPort's high resolution capabilities for Satellite Topography equipment
Perfect for high-res digital signage server control, simplifying access to multiple systems
UPC: 065030839266
In the Box
- StarTech 2-Port Dual DisplayPort USB KVM Switch with Audio & USB 2.0 Hub
- Power Adapter
- 3-Year Warranty
Guides & Manuals
StarTech SV231DPDDUA Specs
| Hardware | Audio: Yes KVM Ports: 2 PC Interface: USB PC Video Type: DisplayPort Multi-Monitor: Yes |
| Connectors | Console Interfaces: 2 x 0.14" (3.5 mm) mini-jack (3 position) female 2 x DisplayPort (20-pin) female 4 x USB A (4-pin) female Host Connectors: 2 x USB B (4-pin) female 4 x 0.14" (3.5 mm) mini-jack (3 position) female 4 x DisplayPort (20-pin) female |
| Performance | DVI Support: Yes - Dual link IP Control: No Maximum Digital Resolutions: WQXGA - 2560 x 1600 Wide Screen Supported: Yes Maximum Number of Users: 1 Port Selection Support: Push button and hotkeys |
| Software | OS Compatibility: OS independent; no software or drivers required |
| LED Indicators | 2 x green - on-line 2 x red - selected PC |
| Power | Power Adapter Included: Yes Input Voltage: 110 ~ 240 AC Input Current: 0.8 A Output Voltage: 12 DC Output Current: 1.5 A Center Tip Polarity: Positive Plug Type: M |
| Certifications | CE, FCC, RoHS |
Environmental
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Storage Temperature | -4 to 140°F (20 to 60°C) |
| Humidity | 0 ~ 80% RH |
Physical Characteristics
| Color | Black |
| Enclosure Type | Steel |
| Dimensions (WxHxD) | 6.3 x 2.3 x 3.9" (161 x 57.5 x 100 mm) |
| Weight | 42.4 oz (1200 g) |
Packaging Info
| Package Weight | 2.6 lb |
| Box Dimensions (LxWxH) | 9.9 x 7.4 x 2.7" |
