Description
Features & Specs
- AMS TMF8801 Time-Of-Flight Sensor
- Direct ToF technology with high sensitivity SPAD detection
- Fast Time-to-Digital Converter (TDC) architecture
- Sub-nanosecond light pulse
- 20 – 2500mm distance sensing @ 30Hz
- On-chip histogram processing
- 940nm VCSEL Class 1 Eye Safety
- High performance on-chip sunlight rejection filter and algorithm
- Industry’s smallest modular OLGA 2.2 x 3.6 x 1.0 mm package
- Supply Voltage: 2.7VMin, 3.0VTyp, 3.3VMax
- Note: Qwiic bus operates at 3.3VMax
- Interrupt breakout pad
- GPIO breakout pads
- Dual Qwiic connectors
- Power LED (configurable)
- I2C pull-ups (configurable)
Features & Specs
- AMS TMF8801 Time-Of-Flight Sensor
- Direct ToF technology with high sensitivity SPAD detection
- Fast Time-to-Digital Converter (TDC) architecture
- Sub-nanosecond light pulse
- 20 – 2500mm distance sensing @ 30Hz
- On-chip histogram processing
- 940nm VCSEL Class 1 Eye Safety
- High performance on-chip sunlight rejection filter and algorithm
- Industry’s smallest modular OLGA 2.2 x 3.6 x 1.0 mm package
- Supply Voltage: 2.7VMin, 3.0VTyp, 3.3VMax
- Note: Qwiic bus operates at 3.3VMax
- Interrupt breakout pad
- GPIO breakout pads
- Dual Qwiic connectors
- Power LED (configurable)
- I2C pull-ups (configurable)
Documentation
- TMF8801 Datasheet
- TMF8801 Host Communication
- SparkFun TMF8801 Arduino Library
- Schematic
- Eagle Files
- Hardware Repo
