Description
With the SparkFun Serial MP3 Player Shield, turn any Arduino into a standalone audio player. Play MP3 and WAV files from a microSD card with simple serial control!
Features & Specs
- MY1690X Serial MP3 IC
- Compatible with .MP3 and .WAV audio files
- Audio Sampling Rate: 8-48K
- Bit Rate: 8-320Kbps
- FAT16 or FAT32 SD formats
- MicroSD cards up to 32GB
- Serial UART Command Set
- Voltage Input: 5V
- USB-C Connector
- 6V/1A Resettable Fuse
- ESD Protection Diodes for USB Data Pins
- Reset Button
- 1x 3.5mm TRRS Connector
- MicroSD Card Socket
- 1x Horizontal Qwiic Connector
- Standard Arduino Uno R3 Footprint
- 2x3 ICSP Passthrough
- LEDs
- Power
- Busy/Playing
- Board Dimensions: 53.34mm x 59.69mm (2.10in. x 2.35in.)
Features & Specs
- MY1690X Serial MP3 IC
- Compatible with .MP3 and .WAV audio files
- Audio Sampling Rate: 8-48K
- Bit Rate: 8-320Kbps
- FAT16 or FAT32 SD formats
- MicroSD cards up to 32GB
- Serial UART Command Set
- Voltage Input: 5V
- USB-C Connector
- 6V/1A Resettable Fuse
- ESD Protection Diodes for USB Data Pins
- Reset Button
- 1x 3.5mm TRRS Connector
- MicroSD Card Socket
- 1x Horizontal Qwiic Connector
- Standard Arduino Uno R3 Footprint
- 2x3 ICSP Passthrough
- LEDs
- Power
- Busy/Playing
- Board Dimensions: 53.34mm x 59.69mm (2.10in. x 2.35in.)
Documentation
- Schematic
- KiCad Files
- Board Dimensions
- Hookup Guide
- Datasheet - MY1690X
- 3D Model
- Qwiic Info Page
- Arduino Library
- GitHub Hardware Repo
