Description
Easily build a custom, wirelessly-connected scale. The OpenScale IoT features an ESP32-PICO-MINI for Bluetooth configuration and WiFi data streaming with any standard load cell.
Features & Specs
- ESP32-PICO-MINI Module
- 2.4GHz WiFi, Bluetooth®, and Bluetooth LE supported
- On-Chip PCB antenna
- Serial configuration menu supported over wired and Bluetooth connections
- Over-the-Air (OTA) firmware updates with WiFi connection
- Operating Voltage: 5V
- Operating Amperage: 80-100mA
- Power Cycling above 500ms
- Selectable 10SPS or 80SPS Output Data Rate
- On Board & External Temperature Sensors
- Fixed & Adjustable Gain
Features & Specs
- ESP32-PICO-MINI Module
- 2.4GHz WiFi, Bluetooth®, and Bluetooth LE supported
- On-Chip PCB antenna
- Serial configuration menu supported over wired and Bluetooth connections
- Over-the-Air (OTA) firmware updates with WiFi connection
- Operating Voltage: 5V
- Operating Amperage: 80-100mA
- Power Cycling above 500ms
- Selectable 10SPS or 80SPS Output Data Rate
- On Board & External Temperature Sensors
- Fixed & Adjustable Gain
Documentation
- Schematic
- KiCad Files
- Board Dimensions
- Hookup Guide
- Datasheets:
- OpenScale - IoT Firmware Binaries
- GitHub Repository
