Description
The MOSFET Power Switch and Buck Regulator (Low-Side) can be powered with up to 12V and control up to 10A, all while providing a sweet 3.3V.
Features & Specs
- Input Voltage Range: 4.5V to 12V
- LMR14203 Step Down Voltage Regulator
- Configured to Output 3.3V/300mA
- PSMN7R0-1000BS N-Channel MOSFET
- Configured as a Low-Side Switch
- Connectors
- Input: 5.5mm x 2.1mm Barrel Jack (Center-Positive)
- Output: Poke-Home Connectors
- Control: 1x4 Female Headers
- 0.1"-spaced PTHs
- Built-in Flyback Diode on Load
- LEDs
- PWR
- ON
- Jumpers
- PWR_LED
- MEAS
- ON_LED
- Dimensions: 1.50" x 1.50" (38.1mm x 38.1mm)
- Weight: 9.9g
Features & Specs
- Input Voltage Range: 4.5V to 12V
- LMR14203 Step Down Voltage Regulator
- Configured to Output 3.3V/300mA
- PSMN7R0-1000BS N-Channel MOSFET
- Configured as a Low-Side Switch
- Connectors
- Input: 5.5mm x 2.1mm Barrel Jack (Center-Positive)
- Output: Poke-Home Connectors
- Control: 1x4 Female Headers
- 0.1"-spaced PTHs
- Built-in Flyback Diode on Load
- LEDs
- PWR
- ON
- Jumpers
- PWR_LED
- MEAS
- ON_LED
- Dimensions: 1.50" x 1.50" (38.1mm x 38.1mm)
- Weight: 9.9g
Documentation
- Schematic
- Eagle Files
- Board Dimensions
- Hookup Guide
- Fritzing Part
- Datasheet
- LMR14203
- PSMN7R0-100BS
- GitHub Hardware Repo
