Description
Sonifex AVN-M8R Overview
The Sonifex AVN-M8R is a professional 8-channel Mic/Line Dante interface that brings high-quality analogue audio directly onto your AoIP network. Housed in a rugged 19" 1 RU aluminum chassis, it distributes eight balanced mic/line inputs to eight Dante/AES67 channels, with full remote control of preamp gain, phantom power, filtering, and input line-up?ideal for broadcast facilities, studios, and live sound environments requiring reliable, configurable, and space-efficient AoIP source integration.
Advanced Mic/Line Input Control
Each of the eight Neutrik balanced XLR inputs offers selectable mic or line operation, with per-channel +48V phantom-power indication and gain adjustment from 16 to 76 dB in 3 dB steps. Line-input configuration includes five selectable line-up levels from +15 to +24 dBu (0 dBFS equivalent), allowing precise tailoring to source equipment. High-pass filtering, corner frequency selection, and signal-presence controls provide additional customization for any operational scenario.
Powerful Remote Management and AoIP Integration
A built-in web server displays all eight inputs in channel-strip format, enabling detailed configuration on a per-channel basis. A convenient Copy Settings function speeds up setup by duplicating mic or line configurations across multiple channels. Channel strips clearly show hardware channel number, Dante Input Name, and user-defined Local Input Name for fast identification. Dante Controller provides full routing flexibility, while compatibility with Ember+ and Dante Domain Manager brings powerful remote-control, monitoring, and system-management options.
Redundant Networking and Reliable PoE Operation
The AVN-M8R supports AES67 for interoperability with other AoIP systems. Dual Gigabit Ethernet ports provide primary and secondary network paths, each supplying power and data redundancy via PoE, ensuring uninterrupted operation in mission-critical environments. Front-panel LEDs display PoE power status, network activity, clock sync status, and secondary port link/PoE monitoring.
Details in Brief
- 8 mic/line inputs using Neutrik connectors
- Per-channel phantom power with LED indication
- Remote input setup via built-in web server
- Mic gain (16 to 76 dB, 3 dB steps)
- Selectable line-up levels (+15 to +24 dBu = 0 dBFS)
- High-pass filter and adjustable corner frequency
- Signal-presence threshold and timeout settings
- Two 1 GB/s RJ45 ports for network and PoE redundancy
- PoE, link, and clock LED indicators
- Configuration via Dante Controller; Dante domain manager compliant
- AES67 compatible
- Powered entirely by PoE
- 1 RU 19" aluminum rack-mountable chassis
- Sonifex AVN-MR8 8-Channel Mic/Line Dante Interface with Dual PoE
-
Limited 1-Year Manufacturer Warranty
Registration Extension: 1-Year
Sonifex AVN-M8R Specs
Key Specs
| Channels of I/O |
Analog:
8 Inputs Digital: 0 Input / 8 Outputs |
| Maximum Sampling Rate |
96 kHz / 32-Bit (PCM)
|
| Number of Microphone Inputs |
8
|
| Analog Audio I/O |
8x XLR 3-Pin Mic/Line Input
|
| Digital Audio I/O |
No
|
| Host Connection |
No
|
| Power Requirements |
PoE
|
General
| Display |
No
|
| Channels of I/O |
Analog:
8 Inputs Digital: 0 Input / 8 Outputs |
| Built-In DSP |
No
|
| Maximum Sampling Rate |
96 kHz / 32-Bit (PCM)
|
| Number of Microphone Inputs |
8
|
| Built-In Microphone |
No
|
| Input Level Adjustment |
8x via Software
|
Signal Processing
| Pad |
No
|
| Gain/Trim Range |
Mic Inputs:
+16 dB to +76 dB (in 3 dB Steps) Line Inputs: +15 dBu to +24 dBu |
| Solo/Mute |
No
|
Connectivity
| Analog Audio I/O |
8x XLR 3-Pin Mic/Line Input
|
| Phantom Power |
48 V (Selectable on Individual Inputs)
|
| Digital Audio I/O |
No
|
| Host Connection / USB |
No
|
| Host Connection Protocol |
No
|
| USB (Non-Host) |
No
|
| Sync I/O |
No
|
| Network I/O |
2x RJ45 AES67
|
| MIDI I/O |
No
|
| Expansion Slots |
No
|
| Wireless |
No
|
Performance
| Frequency Response |
20 Hz to 42 kHz
|
| Impedance |
Mic Inputs:
2.5 Kilohms Line Inputs: > 10 Kilohms |
| THD+N |
Mic Inputs:
< -90 dBFS Line Inputs: < -100 dBFS |
| EIN |
Mic:
< -143 dB Line: < -100 dB |
Digital Audio
| Sample Rates |
Up to 96 kHz
|
| Bit Depths |
16 / 24 / 32-Bit
|
| Sync Sources |
Dante
|
Audio Storage & Playback
| Media/Memory Card Slot |
No
|
Compatibility
| OS Compatibility |
macOS / Windows
|
| Mobile Device Compatibility |
No
|
Power
| Power Requirements |
PoE
|
| Power Consumption |
10 W (Typical)
|
Physical
| Rackmount Size |
1 U
|
| Dimensions |
18.9 x 4.3 x 1.7" / 48 x 11 x 4.3 cm
|
| Weight |
3.1 lb / 1.4 kg
|
