- Key Features
-
- Ultra HD 4K 30 Hz resolution and full 3D
- One HDMI 1.4 input signal split to 16 HDMI 1.4 sink devices
- HDCP 1.3 protocol compliant
- Supports CEC
- Supports deep color 30 bit, 36 bit
- Supports Blu-ray players
- Digital audio format
- Supports signal retiming
- No loss of quality
- Hardware-only solution
UPC: 813280021746
| General |
| Device Type | Video/audio splitter - 16 ports |
| Enclosure Type | Desktop |
| Subtype | HDMI |
| Ports | 16 x HDMI |
| Performance | Bandwidth: 10.2 Gbps |
| Max Resolution | 3840 x 2160 @ 30 Hz |
| Max Video Bandwidth | 320 MHz |
| Features | HDCP compliant, 3D support, CEC passthrough, LPCM 7.1 support, Dolby TrueHD support, 36-bit Deep Color support, DTS support, DTS-HD support, Direct Stream Digital (DSD) |
| Compliant Standards | HDCP 1.3 |
| Status Indicators | Port status, power |
| Power |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Environmental Parameters |
| Min Operating Temperature | 5 �F |
| Max Operating Temperature | 131 �F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
