Description
SmallHD ULTRA 7 Overview
Integrate an ultra-bright monitor into your production rig with this SmallHD ULTRA 7 UHD 4K On-Camera Touchscreen Monitor, which features a 2300 cd/m² display for viewing in just about any indoor or outdoor environment. The 7" monitor features a bright 2300 cd/m² display, a 1920 x 1200 touchscreen LCD, HDMI and 6G-SDI inputs/outputs that support up to 4K, camera control options, tactile buttons, and 10-bit 4:2:2 Rec. 709 color processing. Easily work with ARRI, Sony, and RED cinema cameras thanks to the 5-pin USB and Ethernet control ports.
Onboard button controls offer additional ways to toggle between image functions. All the functionality of the monitor is available via PageOS 5, which provides advanced functionality with a simple and efficient graphical user interface. Upload 3D LUTs via the SD card slot to create consistent aesthetic looks for your footage. An IP53 rating ensures the monitor remains dust and water resistant. Power is delivered to the ULTRA 7 via 2-pin LEMO ports or separately available Gold/V-mount micro battery plate
- Daylight-viewable 7" touchscreen on-camera monitor with 2300 cd/m² brightness
- Slim, lightweight design with 10-bit 4:2:2 DCI-P3 color, touchscreen LCD panel
- HDMI and 6G-SDI inputs and outputs
- Tactile buttons around the monitor allow you to use the monitor in any condition
- The PageOS 5 toolset with EL Zone Exposure Assist, best-in-class waveform, false color, Look-Around Camera Control (sold separately), advanced Teradek RT overlays, and more
- Four 1/4"-20 mounting threads on the left, right, bottom, and back of the monitor
- Power using a 2-pin power input
- Optional RED camera control via the 5-pin USB port
- Optional ARRI/Sony VENICE camera control via the Ethernet port
- Durable aluminum chassis
- Pixel zoom: 2x and 4x with pinch-zoom
- Aspect ratios: Preset and customizable
- DSLR scale: Canon 5D Mk II and Canon 7D
- Custom scale: Underscan only
- Anamorphic de-squeeze: 1.33x, 1.5x, 1.66x, 2.0x
- Image flip: Auto and manual
- Image rotation: Auto and manual
- Cross conversion: HDMI to SDI, SDI to HDMI
- Color focus assist: Adjustable style and intensity
- Peaking: Adjustable intensity
- False color: Spectrum, ARRI-style, and customizable
- Zebra: Dual, customizable
- Waveform: Luma and RGB, customizable with region-of-interest highlighting
- Vectorscope
- RGB parade, customizable
- Histogram: Luma and RGB
- Image capture, with a dedicated button and image gallery
- Custom LUTs: Load as looks on pages or as system-wide calibration via the settings menu
- LUT import: Via SD card or USB storage device
- Image overlay: Opacity slider and blink setting
- Image capture
- Audio meters: Up to eight channels
In the Box
- SmallHD ULTRA 7 UHD 4K On-Camera Touchscreen Monitor
- Limited 1-Year Manufacturer Warranty
Not in the Box
- Essential Battery Plates (Not Included)
Additional Resources
SmallHD ULTRA 7Specs
| Package Weight |
3.145 lb
|
| Box Dimensions (LxWxH) |
12.3 x 8.9 x 2.8"
|
