| ₹ 412390.0 includes GST and import duties. | |
| B2B customers can avail ₹ 62889.48 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
Safely monitor your HD video outdoors with this SmallHD 703 UltraBright On-Camera Monitor Kit with Field Case put together by . The kit includes the SmallHD 703 UltraBright on-camera monitor and the Porta Brace field case with foldout visor, which is custom-designed to fit the 703 monitor.
The 7" monitor features an ultra-bright 2200 cd/m2, 1920 x 1080 display, which provides a sharp image in daylight conditions. It features HDR preview, durable Gorilla Glass, and SDI and HDMI inputs and outputs. The soft field case protects the monitor from scratching and has a foldout visor to protect the monitor from glare. It leaves room for tripod mounting as well as large batteries mounted on the back. Read more below about the items in this kit.
Though monitoring HD video signals outdoors can be difficult, the SmallHD 703 UltraBright On-Camera Monitor, with its 2200 cd/m? bright backlight, overcomes this environmental difficulty. The 7" 1920 x 1080 LCD provides a sharp image, ideal for focus pulling and image analysis on set and in the field. Another advantage of the high-brightness panel is the monitor's ability to preview HDR content. HDR preview extends the display's dynamic range to portray a greater range of brightness in the image.
A unibody aluminum exterior keeps the monitor durable yet lightweight, while also acting as a heatsink for the internal electronics. The LCD panel itself is protected by a layer of optically-bonded Gorilla Glass, notable for its transparency and toughness. The optical bonding process ensures that blacks are not washed out and reduces the harshness of reflections.
On the sides of the display are the SDI and HDMI I/O. Having dual SDI ports allows for A/B viewing of two different SDI signals, or the secondary port can be assigned as an output for sending an SDI signal downstream to another monitor, switcher, or wireless accessory. All the functionality of the monitor is available via the PageBuilder OS, which provides advanced functionality with a simple and efficient graphical user interface.
The Porta Brace Monitor Case for SmallHD 703 Monitor protects the monitor without reducing functionality. Abrasion-resistant 500- and 1000-denier Cordura nylon is used on the outside surfaces of the case, while the interior of the visor is lined with a soft material to help prevent scratches on the screen. Openings around the case enable you to mount the monitor on a tripod, stand, or camera, and provide access to power and video inputs/outputs.
This case's expandable battery cover accommodates both smaller camcorder batteries, as well as larger professional batteries such as V-mount or Gold mount. When fully folded out, an anti-glare visor enables easier viewing outdoors, and a support stand props the monitor up on flat surfaces at a suitable viewing angle. A shoulder strap is included for keeping the monitor close by on the set.
- A foldout visor helps block glare while using the monitor outdoors and tucks out of the way when not needed.
- The inside of the visor is lined with soft loop fabric material to protect your monitor's screen from scratches
- Cable port access on the side of monitor is maintained
- The expandable battery cover enables you to work with larger professional batteries
- The case does not interfere with using the monitor on a stand or camera, handheld, or when used with the included strap
- Made from abrasion-resistant 500- and 1000-denier Cordura nylon
- The Cordura is coated with an extra layer of water-resistant protection
- Triple-tack stitching technique creates maximum strength at seams
Items Included
- SmallHD 703 UltraBright On-Camera Monitor
- SmallHD 2-Pin LEMO to D-Tap Power Cable (36")
- Limited 1-Year Manufacturer Warranty
- PortaBrace Field Case with Foldout Visor for SmallHD 703 Monitor
- Shoulder Strap
- Limited 1-Year Manufacturer Warranty
Not Included
-
BatteriesEssential
-
Battery PlatesEssential
Additional Resources
SmallHD 703 UltraBright On-Camera Monitor
| Display Size |
7.0" / 17.8 cm
|
| Native Resolution |
1920 x 1080
|
| Touchscreen |
No
|
| HDR Support |
Yes
|
| Video I/O |
1x BNC (3G-SDI) Output
1x HDMI Output 1x BNC (3G-SDI) Input 1x HDMI Input |
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC [LUT/Firmware Update Only]
|
| Video Format |
SDI (10-Bit 4:2:2)
1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50/30/29.97/25/24/23.98 480i 576i HDMI (8/10/12-Bit) 1080p: 60/59.94/50/30/25/24/23.98 1080PsF: 30/25/24/23.98 1080i: 60/59.94/50 720p: 120/119.88/100/60/59.94/50/30/25/24/23.98 576p: 100/50 480p: 120/119.88/60/59.94 480i: 240/239.76/120/119.88/60/59.94 576i: 200/100/50 |
| Battery |
No
|
| Power Consumption |
13 W
|
| Panel Type |
TFT LCD
|
| Display Size |
7.0" / 17.8 cm
|
| Native Resolution |
1920 x 1080
|
| Aspect Ratio |
16:9
|
| Viewing Angle |
Horizontal: 178? (89/89)
Vertical: 178? (89/89) |
| Touchscreen |
No
|
| Maximum Brightness |
2200 nits / cd/m2
|
| Contrast Ratio |
1200:1
|
| Color Support |
1.07 Billion Colors (10-Bit)
|
| HDR Support |
Yes
|
| Color Gamut |
100% Rec. 709
|
| LUT Support |
No
|
| Image Controls |
Blue Only, False Color, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Screen Markers, Waveform
|
| Video I/O |
1x BNC (3G-SDI) Output
1x HDMI Output 1x BNC (3G-SDI) Input 1x HDMI Input |
| Embedded Audio |
HDMI
SDI |
| Audio I/O |
1x 1/8" / 3.5 mm Headphone Output
|
| Built-In Speaker |
No
|
| Power I/O |
1x LEMO 2-Pin Input
1x LEMO 2-Pin Output |
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC [LUT/Firmware Update Only]
|
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Mobile App Compatible |
No
|
| Video Format |
SDI (10-Bit 4:2:2)
1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50/30/29.97/25/24/23.98 480i 576i HDMI (8/10/12-Bit) 1080p: 60/59.94/50/30/25/24/23.98 1080PsF: 30/25/24/23.98 1080i: 60/59.94/50 720p: 120/119.88/100/60/59.94/50/30/25/24/23.98 576p: 100/50 480p: 120/119.88/60/59.94 480i: 240/239.76/120/119.88/60/59.94 576i: 200/100/50 |
| Input Power |
6 to 34 VDC
|
| Battery |
No
|
| Power Consumption |
13 W
|
| Tripod/Accessory Mounting |
Back
2x 1/4"-20 Female |
| Environmental Resistance |
No
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 404142.2 |
| 3-5 | ₹ 400018.3 |
| 5-10 | ₹ 391770.5 |
| 10+ | ₹ 383522.7 |
Bulk discount will be automatically applied during checkout based on quantity.
