Description
SimplyTEST ST-158006 Overview
- 1Description
- 2VDV II PRO Features at a Glance
- 3Accuracy
- 4Intelligent Detection
The SimplyTEST VDV II PRO Cable Tester expands upon the efficiency of the VDV II PLUS with TDR technology, media service detection, and PoE++ network information, providing up to 90W of testing power. A 6-pin RJ-11/RJ-12 port, an RJ45 port, and a Coax F-type port on the VDV II allow you to connect and verify copper cables typically found in domestic, commercial, or industrial applications. The VDV II PRO can subsequently measure the cable's length and determine the signal running through the cable-from ISDN and PBX telephone services to PoE.
Powered pairs, network rate, and voltage information among other information, is displayed on the large, 2.9" backlit screen of the VDV II PRO. TDR information is efficiently generated by the device to determine distance to fault and pinpoint damage to the cable. The included remote unit or dual-port remote unit can be embedded into the bottom of the device for easy storage and portability. Various cables and connectors included with the VDV II PRO allow you to test different cable types and connections with a singular device. The VDV II PRO is powered by an included 9V alkaline battery and it can be stored with all of tis accessories in the carrying case.
- Increased detection capabilities
- Includes cables, connectors, and carrying case
- Calibrates via velocity of propagation
- Comprehensive details on opens, shorts, crossovers, and split pairs
- Integrated RJ-11/RJ-12 (voice), RJ45 (data), and coax F-type (video) connectors for faster testing of most cables
- Remote unit can be stored in bottom of device
- Support for all common LAN cables: Cat 5/5e/6/6a/7, UTP, and STP
- Large 2.9" backlit screen for easy-to-read results
- Voltage protection disables testing if more than 2V is detected
- Utilizes TDR to accurately measure cable length and provide distance to fault information
- Maximum cable length 980' for wiremap cables and 1960' overall
- Injects a signal into the cable and measures the time it takes for that signal to be reflected back
- Analyzes changes in impedance caused by cable damage, open, and short circuits
- Recorded time is then translated into accurate distance measurement
- Helps pinpoint where cabling faults occur and speeds up fault finding
- By detecting presence of voltage and checking polarity, determines which media service is running over the cable (ISDN, PBX, and PoE)
- Troubleshooting active Ethernet networks is made easier with built-in network detection that displays network rate and duplex info
In the Box
- SimplyTEST PoE Pro AnyWARE VDV II Cable Tester for PoE++
- Dual-Port Remote Unit
- Coax Remote Unit
- 2 x RJ45 to Alligator Clip Cable (15.4")
- 2 x RJ45 to RJ45 Cable (5.9")
- 2 x RJ-12 to RJ-12 Cable (3.9")
- F-Type Plug Cable (9.1")
- F-81 Barrel Splice
- BNC Female to F-Type Male Adapter
- BNC Female to F-Type Female Adapter
- RCA Female to F-Type Male Adapter
- RCA Female to F-Type Female Adapter
- Wallet Wiring Card
- 9V Alkaline Battery
- Carry Case
- Limited 2-Year Manufacturer Warranty
- Description
- VDV II PRO Features at a Glance
- Accuracy
- Intelligent Detection
SimplyTEST ST-158006 Specs
| Panel Type |
LCD
|
| Display Size |
2.9"
|
| Touchscreen |
No
|
| Video I/O |
1x Coaxial F-Type Input
|
| Audio I/O |
2x RJ45/etherCON Coaxial Input (RJ11 and RJ45 with PoE)
|
| Power Source |
Battery (Included)
|
| Battery Type |
1x 9 V
|
| DC Input Power |
9 VDC
|
| Color |
Blue
|
| Dimensions |
12.7 x 7.5 x 2.4" / 32.3 x 19.1 x 6.1 cm
|
| Weight |
Not Specified by Manufacturer
|
| Package Weight |
1.865 lb
|
| Box Dimensions (LxWxH) |
12.65 x 7.95 x 2.5"
|
