Simply45 Cat 5e/6/6a STP Shielded Internal Ground RJ45 Standard Modular Plug (50-Piece Jar)

Cat 5e/6/6a Shielded RJ45 Modular Plug

Internal Ground

Supports Solid and Stranded LAN Cables

Gold-Plated 3-Prong Pins

Designed to work with shielded twisted pair (STP) LAN cables, the Simply45 Cat 5e/6/6a STP Shielded Internal Ground RJ45 Standard Modular Plug connects onto 24 AWG solid and 28-26 AWG stranded LAN cables up to 0.24" in diameter. Fifty single piece standard modular RJ45 plugs with overall internal ground shielding come packed inside of a convenient plastic jar, which work with most Cat 5e, Cat 6, and Cat 6a LAN cables.. Each plug features a 3-prong pin design with 50? 24kt gold plating to help deliver high electrical conductivity and a stronger connection to wire conductors and has a light blue tint for easy identification. These modular plugs are rated to work with PoE and PoH devices.

3-Prong Pin Design Simply45's 3-prong pins feature 50? of 24kt gold plating. Having a 3-prong pin provides three points of contact with the copper wire conductor, which provides a strong connection for high electrical performance and improved signal integrity with less heat build-up compared to a 2-prong connection. UPC: 817777017786

Type	RJ45 Male
Quantity	50
Contact Plating	50 µ Gold 100 µ Nickel
Contact Material	Bronze
Shielded	Yes
Conductor Diameter	0.04" / 1.05 mm
Contact Resistance	20 milliohms

Supported Cable Diameter	0.2" / 6.1 mm
Wire Gauge Supported	24 to 28 AWG
Cable Types Supported	Solid, Stranded
Networking Type	Cat 5e, Cat 6, Cat 6a

Plug Material	Polycarbonate
Compliance	RoHS, UL, FCC
Flame Resistance Rating	UL94V-0
Mating Cycles	2000
Operating Temperature	-40 to 158°F / -40 to 70°C

Package Weight	0.37 lb
Box Dimensions (LxWxH)	3.15 x 2.55 x 2.55"
