Description
Product Overview
6SL3246-0BA22-1FA0 is a SINAMICS G120 series, DC motor inverter.
- 24VDC power module, 20 to 29VDC external power supply
- 2A maximum power consumption, 12W power loss
- PROFINET, Ethernet/IP communication, 15 standard digital inputs
- 2 number digital outputs, DC 30V, 0.5A output (resistive load)
- 2 (differential input), 2 (non-isolated output)
- 95% max relative humidity operation, IP20/UL open type degree of protection
- UL, cUL, RCM, SEMI F47 standards
- 0.05 to 1.50mm² (AWG 28 to AWG 16) conductor cross-section
- Dimension is 73 x 199 x 67mm (W x H x D)
- Ambient temperature range from -10 to 50°C
Product details
Other details
| Brand | SIEMENS |
| Part Number | 6SL3246-0BA22-1FA0 |
| Quantity | Each |
| Technical Data Sheet EN |  |
