The SSC1000-25-24 is a panel-mount Solid State Relay with IGBT output. It has redesigned housing with anti-rotation barriers. It has aluminium base plate and a current regulated nominal input impedance.
- Improved SEMS screw and washer
- DC control
- Epoxy-free design
- 3750Vrms Input/output dielectric strength
- 10�R Minimum insulation resistance
- 8pF Input/output maximum capacitance
- UL94V-0 Flammability rating
- -40 to 80°C Operating temperature range
Applications
Industrial
Warnings Hazard of electric shock, explosion or arc flash. Disconnect all power before installing or working with this equipment. Verify all connections and replace all covers before turning ON power.
Product details
| Contact Configuration |
SPST-NO |
| Load Current |
25A |
| Operating Voltage Max |
1000VDC |
| Relay Mounting |
Panel Mount |
| Relay Terminals |
Screw |
| Switching Mode |
DC Switch |
| Operating Voltage Min |
0VDC |
| Control Voltage Min |
20VDC |
| Control Voltage Max |
28VDC |
| Product Range |
- |
Other details
| Brand |
SENSATA/CRYDOM |
| Part Number |
SSC1000-25-24 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
| Drawing EN |
|
| Product Change Notice EN |
|
