Description
The PF480D25 is a PCB mount Solid State Relay feature SCR output for heavy industrial loads and DC control input. The zero voltage turn-on comes with normally open output and thermally conductive epoxy encapsulation.
- 1200Vpk Transient overvoltage
- 0.1mARMS Maximum off-state leakage current at rated voltage
- 250Apk Maximum surge current (16.6ms)
- 1.6Vpk Maximum on-state voltage drop at rated current
- 4000VRMS (50/60Hz) Input/output/base dielectric strength
- 10�R at 500VDC Minimum insulation resistance
- 8pF Input/output maximum capacitance
Industrial
Warnings Risk of material damage and hot enclosure, it's side panels may be hot, allow the product to cool before touching. Follow proper mounting instructions including torque values.Other details
| Brand | SENSATA/CRYDOM |
| Part Number | PF480D25 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 4193.59 |
| 3-5 | ₹ 4150.79 |
| 5-10 | ₹ 4065.21 |
| 10+ | ₹ 3979.63 |
Bulk discount will be automatically applied during checkout based on quantity.
