Description
Product Overview
GNR10DCZ is a GNR series din rail mount solid state relay. Approvals are designed in accordance with the requirements of IEC 62314, IEC 62314, IEC 60068-2-6 35mm/10-55Hz, IEC 60068-2-27 15G / 11ms IEC 61000-4-2 Level 3 Electrostatic Discharge, IEC 61000-4-3 Level 3 Radiated Electromagnetic Noise, IEC 61000-4-4 Level 3 Immunity to Electrically Fast Transients, IEC 61000-4-5 Level 3 Immunity to Electrical Surges, IEC 61000-4-6 Level 3 Conducted Electromagnetic Noise.
- Direct bond copper (DBC) substrate, LED input status indicator
- Built-in overvoltage protection, zero voltage turn-on output
- 10 Amps rated load current, control voltage range from 4 to 32VDC
- Contactor configuration terminal layout, zero voltage turn-on switching type
- Operating voltage range from 24 to 280Vrms, 16/10 AWG min/max solid wire
- UL 94V0 (self extinguishing) housing material, green LED input status indicator
- Current regulated input resistance
- Maximum turn-off time is 1/2msec cycle
- Maximum turn-on time is 1/2msec cycle
- Ambient operating temperature range from -20 to 80°C
Product details
Other details
| Brand | SENSATA/CRYDOM |
| Part Number | GNR10DCZ |
| Quantity | Each |
| Technical Data Sheet EN |  |
