Description
The TA45-ABTWF160C0 is a 16A 2-pole rocker Circuit Breaker for equipment, rocker actuated version of the TA45 line of thermal CBE's can be used for various purposes. Basically it is a CBE for automatic interruption of overloads with facilities for regular manual ON or OFF switching operations under normal load conditions. It is capable of interrupting moderate short-circuit currents without the aid of backup protection. Panel mounted with 240VAC/60VDC supply voltage.
- IP40 Protection rating
- 4000VAC Dielectric strength
- >100MR at 5000VDC Insulation resistance
- -10 to 55�C Permissible ambient temperature range
- Thermal positively trip-free
- Under-voltage release (zero-voltage release)
- Remote trip
- Mechanical lock-out latch
Applications
Motor Drive & Control, Power Management
Product details
| Voltage Rating V AC | 240VAC |
| Current Rating | 16A |
| Product Range | TA45 Series |
| Circuit Breaker Mounting | Panel |
| Voltage Rating V DC | 60VDC |
| No. of Poles | 2 Pole |
Other details
| Brand | SCHURTER |
| Part Number | TA45-ABTWF160C0 |
| Quantity | Each |
| Technical Data Sheet EN |  |
