Description
The EC11.0021.001 is a red GST IEC C20 Power Entry Module with filter. It has a 2-pole line switch and 6.3x0.8mm quick connect terminals. It is suitable for appliances with protection class I according to IEC 61140. The housing is made of black UL94V-0 thermoplastic. The connector is equipped with a notch intended for use with the latching cordset. The cord latching system prevents against accidental removal of the cordset.
- All single elements are already wired
- Line switch non-illuminated or illuminated
- Ideal for application with high transient loads
- Suitable for use in equipment according to IEC/UL 60950
- IP40 Protection rating
Applications
Power Management
Product details
| Gender | Plug |
| Current Rating | 16A |
| Product Range | EC11 Series |
| Contact Termination Type | Quick Connect |
| Voltage Rating | 250VAC |
| Connector Mounting | Panel Mount |
Other details
| Brand | SCHURTER |
| Part Number | EC11.0021.001 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Application Note EN | |
