Description
Schneider Tourmaline Overview
- 1Description
- 2Sensor Coverage
- 3Compact Design
- 4Antireflective Coating
- 5Sony Pregius Compatible
- 6TFL Mount
- 7Applications
The TFL-mount Tourmaline 20mm f/2.0 TFL-Mount Lens has a compact, robust build optimized for machine vision, traffic, and surveillance applications. This lens supports up to 1.3" sensors and is compatible with all generations of Sony Pregius sensors. It features an f-stop range of 2.0 to 16, a broadband antireflective coating, and focus and iris locks. This lens is the manual focus and iris version.
Sensor Coverage
Produces optimal quality images for sensors measuring up to 1.3"/24mm diagonal
Compact Design
This Tourmaline lens features a compact, rugged design ideal for demanding environments
Antireflective Coating
This lens's broadband antireflective coating makes it suitable for use in the visible (400-700nm) or near-infrared (700-1000nm) spectrum
Sony Pregius Compatible
The low chief ray angle is suitable for all generations of Sony Pregius sensors
TFL Mount
This 20mm lens is one of a series of eight focal lengths that are compatible with a range of industrial cameras
Applications
A robust build suits this Tourmaline lens for traffic, surveillance, and machine vision applications
Table of Contents
- Description
- Sensor Coverage
- Compact Design
- Antireflective Coating
- Sony Pregius Compatible
- TFL Mount
- Applications
Schneider Tourmaline Specs
| Lens Mount | TFL |
| Sensor Compatibility | 1.3" |
| Focal Length | 20mm |
| Maximum Aperture | f/2 |
| Minimum Aperture | f/16 |
| Angle of View | 1.3" Sensor Horizontal: 61° |
| Minimum Focus Distance | From Unspecified Point in Lens: 7.6" / 194 mm |
| Focus Type | Manual Focus |
| Iris Type | Manual |
| Storage Temperature | -13 to 158°F / -25 to 70°C |
| Filter Thread | M37.5 x 0.5 mm |
| Dimensions (ø x L) | 1.9 x 2.5" / 48 x 62.9 mm |
| Weight | 15.9 oz / 450 g |
