Samtec SSW-113-01-G-D SSW-113-01-G-D PCB Receptacle Board-to-Board 2.54 mm 2 Rows 26 Contacts Through Hole Mount SSW

The SSW-113-01-G-D is a 26-pole 2-row 2.54mm Through-hole SQ Post Socket Strip with 20?inch (0.51?m) gold-plated phosphor bronze contacts and LCP insulator. The SSW series straight pin socket strip compatible with DW, EW, HCMD, HCMS, HHSC, HMTSW, HTSS, HT

• 5.7A Current rating
• Lead-free solderable
• 10mR Contact resistance
• 0.145" (3.68mm) to 0.250" (6.35mm) Insertion depth
• Standard and low insertion force contacts with standard solder tails
• Contact material is phosphor bronze

Applications

Industrial

Other details

Brand	SAMTEC
Part Number	SSW-113-01-G-D
Quantity	Each
Technical Data Sheet EN
