Samtec FTSH-103-02-L-D-RA FTSH-103-02-L-D-RA Pin Header Right Angle Board-to-Board Wire-to-Board 1.27 mm 2 Rows 6 Contacts

The FTSH series from Samtec are through hole micro terminal strip headers. It mates with Samtec FFSD, FFTP, CLP and FLE series of connectors. These terminal strip headers are available in end shroud, end shroud with locking clip, end shroud with guide post, end shroud with board lock, ejector shroud and keying shroud option.

• Available in dual row
• Pitch spacing is 1.27mm (2 to 50 contacts per row) with right angle (-RA) orientation
• Operating temperature range of -55?C to 125?C
• Contact material is phosphor bronze
• Black liquid crystal polymer insulator material
• Complies with UL E111594 and CSA 090871
• 0
• 000 standards
• 10?" gold plated contacts

Applications

Industrial

Other details

Brand	SAMTEC
Part Number	FTSH-103-02-L-D-RA
Quantity	Each
Technical Data Sheet EN
Drawing EN
