Description
Russound UD1290 Overview
The Russound D1290 Amplifier is a robust 12-channel Class-D digital amplifier designed for larger spaces and outdoor areas, delivering the power and flexibility to elevate any audio system. Whether you're looking to enhance your home theater experience with rich, immersive sound or power multiple speakers throughout your home with your favorite music, the D1290 is engineered to meet the challenge. With 90W per channel across six zones, this advanced digital amplifier ensures consistent, high-quality audio performance. Each zone has three input options�two shared bus inputs and a dedicated zone input�giving you versatile control over your audio sources. For even more power, zones can be bridged to deliver up to 180W, making the amplifier ideal for driving outdoor speakers or filling larger rooms with clear, dynamic sound.
One of the standout features of the D1290 is its built-in audio filter for each zone. A simple slide switch on the rear panel allows you to select between full-range sound, a high-pass filter for smaller or architectural speakers, or a low-pass filter for subwoofer use. This enables you to tailor the amplifier�s output precisely to the speakers in each zone, optimizing sound quality throughout your system. Additional control features include three turn-on modes: Always On, Signal Sensing, and 12V Trigger Control, giving you flexibility in system integration. All of this is wrapped in a sleek new industrial design that looks great on a shelf or fits neatly into a standard 19" rack.
- 12-channel premium performance amplifier
- 6 zones with individual volume gain
- 90W per channel at 4 Ohms
- 45W per channel at 8 Ohms
- 180W at 8 Ohms (bridged)
- 3 input options for every channel: 2 bus inputs and 1 line input
- 3 Power-On modes: Always On, Signal Sensing, 12V Trigger
- Audio Filters: Full-Range, Low-Pass: 20 Hz to 160 Hz, High-Pass: 80 Hz to 20 kHz
- Speaker connectors: detachable screw-down
- Internal cooling fan
- 19" 1 RU rackmount industrial design
Items Included
- Russound D1290 12-Channel Digital Power Amplifier
- Set of Removable, Screw-Down 4-Pin Speaker Connectors
- Set of Rackmount Ears with Attachment Screws
- Power Cord (6')
- Limited 2-Year Manufacturer Warranty
Additional Resources
Guides & Manuals
Russound UD1290 Specs
| Number of Channels |
12
|
| Amplifier Power Rating |
4 Ohms:
90 W per Channel 8 Ohms: 45 W per Channel 8 Ohms: 180 W Bridged |
| Load Impedance / Voltage |
4 / 8 Ohms
|
| Analog Audio I/O |
2x 2RCA Coaxial Female Input
6x 2RCA Coaxial Female Output 6x Block 4-Pin Female |
| Digital I/O |
No
|
| Network I/O |
No
|
| Rackmount Size |
1 U (with Included Hardware)
|
| Number of Channels |
12
|
| Amplifier Power Rating |
4 Ohms:
90 W per Channel 8 Ohms: 45 W per Channel 8 Ohms: 180 W Bridged |
| Amplifier Class |
Class-D
|
| Load Impedance / Voltage |
4 / 8 Ohms
|
| Protections |
No
|
| Frequency Response |
20 Hz to 20 kHz ±3 dB
|
| Input Sensitivity |
690 mV
|
| Input Impedance |
Line:
>22 Ohms |
| Audio Delay |
No
|
| Crossover |
No
|
| EQ |
No
|
| Filters |
1x High-Pass
1x Low-Pass |
| Ducking/Muting |
No
|
| Limiting |
No
|
| Analog Audio I/O |
2x 2RCA Coaxial Female Input
6x 2RCA Coaxial Female Output 6x Block 4-Pin Female |
| Digital I/O |
No
|
| Network I/O |
No
|
| Other I/O |
1x 1/8" / 3.5 mm 12 V Trigger Input
1x 1/8" / 3.5 mm 12 V Trigger Output |
| USB I/O |
No
|
| Mobile App Compatible |
No
|
| Wireless |
No
|
| AC Input Power |
115 to 120 VAC, 60 Hz
|
| AC Power Connector |
IEC
|
| Display & Indicators |
LED
|
| Rackmount Size |
1 U (with Included Hardware)
|
| Cooling |
Fan
|
| Dimensions |
17.1 x 1.7 x 9.7" / 43.4 x 4.3 x 24.6 cm
|
| Weight |
9 lb / 4.1 kg
|
| Package Weight |
13.41 lb
|
| Box Dimensions (LxWxH) |
21.1 x 14.9 x 6"
|
