GP-02-Kit is a highly integrated SOC development board with ceramic antenna and GP-02 high performance BDS/GNSS multi-mode satellite navigation receiver. The main chip is AT6558R satellite positioning chip. Integrated radio frequency front end, digital baseband processor, 32-bit RISC CPU, power management and active antenna detection and protection functions. Support a variety of satellite navigation systems, including China's BeiDou Navigation Satellite System (BDS), the United States' GPS, and Russia's GLONASS, which can realize multi-system joint positioning. GP-02-Kit follows the NMEA protocol and sends instructions through serial communication to control the work content of the development board.
- Size 23.4x12.2x24(±0.2)MM
- Operating temperature range from -40°C to 85°C
- Power supply typical 5V (support micro USB 5V power supply)
- Maximum support 256000bps
Product details
| Kit Application Type:
Sensing - Navigation, Position
|
| Silicon Manufacturer:
Shenzhen Qianle Microelectronics Technology
|
| Silicon Core Number:
AT6558R
|
| Application Sub Type:
BDS / GNSS
|
| Kit Contents:
Development Board AT6558R
|
| Product Range:
-
|
Other details
| Brand |
RF SOLUTIONS |
| Part Number |
GP-02-KIT |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
