Description
RF-Links ZD-500W Overview
Amplify your digital or analog broadcast signal with the LD-MOS Broadcast UHF Power Amplifier from RF-Links. This 3 RU rackmount amplifier features a durable chassis and provides 500W power output for analog or digital RF broadcasts in the 470 to 862 MHz signal range. The unit can be controlled via its RS-232 and RS-485 serial interfaces, and control software is included.
Key Features
Full LD-MOS Power Amplifier
500 Wps Out
150 Wrms Out DVB-T
DTV (8 VSB): 275 Wrms
Broadband (470-862 MHz)
Designed for SKD sales
Internal cabling free
Easy maintenance without special tools
RS-232-RS-485 interface
Control software included
Durable mechanical structure
In the Box
- RF-Links LD-MOS Broadcast UHF Power Amplifier (470-862 MHz)
- Limited 90-Day Manufacturer Warranty
RF-Links ZD-500W Specs
Inputs / Outputs
| Video I/O |
1 x SMA Input
1 x SMA Output 1 x SMA Monitor Output |
Power
| Power Source |
AC Input
|
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz at 7.5 A
|
| Power Consumption |
500 W (Typical)
|
Environmental
| Operating Temperature |
32 to 113°F / 0 to 45°C
|
| Operating Humidity |
90% (Non-Condensing)
|
Physical
| Dimensions |
23.6 x 17.2 x 5" / 600 x 437 x 127 mm
|
| Weight |
46.3 lb / 21 kg
|
