Description
The REV Robotics SRS is a metal-geared smart servo configurable between 270° positional and continuous-rotation modes via optional programming, delivering 13.5 kg-cm torque at 6 V, with durable 25-tooth spline gearing and a compact form factor.
Features & Specs
- Speed: 0.14s/60° (at 6V) - Note this speed is slightly lower for current inventory than previously stated (.14s/60° vs the .13s/60°)
- Stall Torque: 13.5 kg-cm / 187.8 oz-in (at 6V)
- Stall Current: 2A (at 6V)
- Voltage Rating: 4.8V – 7.4V, 6V nominal
- Input Pulse Range: 500μs – 2500μs
- Default Angular Range: 270°
- Maximum programmable range in angular mode - 280°
- Gear Material: Metal
- Spline type – 25T
- Spline Internal Thread Size: M3
- Spline Internal Thread Depth: 6mm
- Size: 40.2mm x 20.0mm x 38.0mm
- Weight: 2.05 oz.
Features & Specs
- Speed: 0.14s/60° (at 6V) - Note this speed is slightly lower for current inventory than previously stated (.14s/60° vs the .13s/60°)
- Stall Torque: 13.5 kg-cm / 187.8 oz-in (at 6V)
- Stall Current: 2A (at 6V)
- Voltage Rating: 4.8V – 7.4V, 6V nominal
- Input Pulse Range: 500μs – 2500μs
- Default Angular Range: 270°
- Maximum programmable range in angular mode - 280°
- Gear Material: Metal
- Spline type – 25T
- Spline Internal Thread Size: M3
- Spline Internal Thread Depth: 6mm
- Size: 40.2mm x 20.0mm x 38.0mm
- Weight: 2.05 oz.
